HZW-HA-010-F

Part Number：80210010120

INQUIRY

Product description

Specifications:

Inserts:

Number of contacts: 10+PE

Rated current： 16A

Rated voltage： 250V

Rated impulse voltage： 4KV

Pollution degree： 3

Rated voltage acc.to UL/CSA: 600V

Insulation resistance: ≥10¹⁰Ω

Material： Polycarbonate

Limiting temperatures： -40℃~+125℃

Flammability acc.to(UL94): V0

Mechanical working life -mating cycles: ≥500

Contacts:

Terminal: screw terminal

Material: Brass

Surfac: hard-silver plated

Contact resistance: ≤1mΩ Crimp terminal

Wire gauge--mm²: 1.0~2.5mm²

Wire gauge--AWG: 18-14

Tightening/Test torque：0.5N ·m

Heavy duty connector is designed for strong and stable electrical or mechanical connections, offering high durability, excellent load capacity, and reliable performance in industrial, construction, and demanding environments with long service life and safe operation.
