HZW-HD-007-FC

Part Number：80220007220

INQUIRY

Product description

Specifications:

Inserts:

Number of contacts: 7+PE

Rated current： 10A

Rated voltage： 250V

Rated impulse voltage： 4KV

Pollution degree： 3

Rated voltage acc.to UL/CSA: 600V

Insulation resistance: ≥10¹⁰ Ω

Material： Polycarbonate

Limiting temperatures： -40℃~+125℃

Flammability acc.to(UL94): V0

Mechanical working life -mating cycles: ≥500

Contacts:

Terminal: Crimp terminal

Material: Brass

Surfac: hard-silver plated/Gold plated

Contact resistance: ≤3mΩ Crimp terminal

Wire gauge--mm²: 0.14~2.5mm²

Wire gauge--AWG: 26-14
