HZW-HDD-072-FC

Part Number：80230072220

INQUIRY

Product description

Specifications:

Inserts:

Number of contacts: 72+PE

Rated current: 10A

Rated voltage: 250V

Rated impulse voltage: 4KV

Pollution degree: 3

Rated voltage acc.to UL/CSA:600V

Insulation resistance: ≥10¹⁰Ω

Material: Polycarbonate

Limiting temperatures: -40℃~+125℃

Flammability acc.to(UL94): V0

Mechanical working life-mating cycles: ≥500

Contacts:

Terminal: Crimp terminal

Material: Brass

Surfac: hard-silver plated/Gold plated

Contact resistance: ≤3mΩ

Crimp terminal

Wire gauge--mm²: 0.14~2.5mm²

Wire gauge--AWG: 26-14
